RBAI Robotic Intelligent Tracking Control System

- Takes SDI signal from main camera and performs face and skeleton animation recognition based on main camera focal length - Intelligent left, center, right and full, medium, close-up shot framing, with customizable locked framing. Can automatically switch between different shots for convenient filming. - When framing multiple people, can select tracking target to prevent losing or occlusion interference. - Supports gesture recognition, raising left hand locks tracking target. Gesture recognition enables precise target selection with multiple people. - Auto tracking delay less than 0.1 seconds - Object recognition auto focus

- Takes SDI signal from main camera and performs face and skeleton animation recognition based on main camera focal length

- Intelligent left, center, right and full, medium, close-up shot framing, with customizable locked framing. Can automatically switch between different shots for convenient filming.

- When framing multiple people, can select tracking target to prevent losing or occlusion interference.

- Supports gesture recognition, raising left hand locks tracking target. Gesture recognition enables precise target selection with multiple people.

- Auto tracking delay less than 0.1 seconds

- Object recognition auto focus



1 Main Interface Functions:

Control buttons for the robotic camera support equipment's tilt, pan, zoom focus movements, adjust motion speed, select programs, etc. Can display real-time position data. System config allows adjusting communication, language, parameters and other settings, saves and takes effect immediately. Can preset 32 programs, 16 sequences per program, 16 scenes per sequences. Long press program buttons to edit names. Home button resets device to initial home position, can lock control handle to prevent misoperation. Tap close button in top right corner to exit software and return mount to home position. Collision avoidance system can display warnings and stop robotics shooting motion. Supports importing/exporting programs and scenes for backup.



2. Scene Selection:

Tap a saved scene and the equipment will move according to the preset trajectory. The interface buttons will light up to indicate motion status. If an anomaly occurs during motion, tap the Pause button and the equipment will immediately stop all motion commands. Tapping the scene button again will cause the system to check if the anomaly has been cleared and resume normal operation if so. The Home button resets the device to the initial home position. After selecting a scene, the speed lock can be opened for speed adjustment.


3. Scene Editing:

The left/right joysticks control equipment movement. Tap an empty button at the desired position to save the scene. Long press a scene to edit its name. Press the delete icon on buttons with saved scenes to immediately delete it. The Home button resets the device position.



System configuration:

- 12th Gen Intel® Core™ i5-12450H Processor (performance mobile processor)

- NVIDIA® GeForce RTX™ 3050 Laptop GPU

- 16GB DDR5 4800MHz

- 512GB PCIe 4.0 SSD

- 16" LCD fully laminated display, 2560 x 1600 resolution

- WiFi 6 wireless and Gigabit ethernet

- SDI capture input

- Windows 11 64-bit Enterprise Edition

- Robotic intelligent camera control system software suite

系统配置:

HP Z4 G4工作站,配置为:

1x Intel 64位至强处理器W2255 10核 3.7 G - 4.5 G 19.25 MB/32 GB DDR4 (2x16 GB)内存 /GPU图形计算卡/

256GB m.2 SSD + 企业级4TB/24寸触控屏/SDI识别输入/win10 64位企业版/机器人摄像控制系统软件一套
