Multi-channel ST 2110 IP video server for video file playout.
Standard VDCP-TCP and AMCP control protocols.
2 × UHD channels or 4 × HD channels video outputs.
Supports MXF formats including XAVC 300, XAVC 100, and XDCAM HD.
Supports long file names and dual-channel A/B switching.
Compliant with ST 2110-10/20/21/30/40 and ST 2022-7.
Supports video formats: HD 1080 50/59.94i/60i/p and UHD 2160 50p/59.94p/60p.
Supports PTP and NMOS IS-04/05 protocols.
Web-based management with real-time monitoring of CPU, memory, and network status.
x86 architecture, embedded OS, 24/7 operation.
Supports software-defined functionality (SDF).
Supports 2.5Gb NAS transfer and network control, plus USB4 external storage via USB-C.
Hardware Configuration
2U server
4 TB high-speed SSD
1 × USB-C (40Gb)
1 × 100Gb data port
1 × 2.5Gb management port
1 × Redundant power supplies
| Basic Functions | |
| System Architecture | X86 architecture, embedded OS |
| Function Expansion | Elastic computing expansion; software-defined functions |
| Control Protocols | Standard VDCP-TCP, AMCP |
| Stream Out | 2× 4K broadcast, 4× HD broadcast |
| File Format | MXF (XAVC300, XAVC100, XDCAM HD, etc.) |
| Long Filenames | Supports reading long-named video files |
| AB Operation | Dual-channel AB switching |
| Standards | ST2110-10/20/21/30/40, ST2022-7 |
| NMOS | Supports NMOS IS-04/05 for stream configuration and control |
| LSM Management | Quick setup of I/O sources, PTP, and stream monitoring |
| PTP Sync | 1588V2, 2059-2, ST2110-10 |
| HD Formats | 1080 50i/50P/59.94i/60i/60P |
| UHD Formats | 2160 50P/60P/59.94P |
| WEB Management | Real-time CPU, memory, and NIC monitoring |
| Audio Delay | Supports input/output delay |
| Frame Sync | SDI input frame sync |
| Basic Specifications | |
| SDI Interfaces | 4 SDI outputs (12G/3G/1.5G) |
| Data NIC | 100Gb QSFP28 × 1 |
| Mgmt NIC | 2.5Gb RJ45 × 1 |
| External Drive | USB4 external data drive support |
| Server Chassis | 2U rack-mount, 485 × 450 × 89 mm |
| Media Drive | 4TB M.2 |
| Power | 100–120V / 200–240V 50/60Hz, 500W edundant power supply |
| Storage Temp | –20~60°C |
| Operating Temp | –10~40°C |
| Stability | 24/7 operation |
| Certification | NRTA MA & CNAS reports |
