Product Features:
The prompting screen adopts a 21.5-inch display, weighs 8.5 kg, and uses multi-layer broadband dielectric beam splitter (hard-coated) glass with a thickness of only 2 mm.
Control methods are flexible and diverse: keyboard, mouse, and wireless remote control are all supported. The subtitle speed range can be freely adjusted, and jumping between segments is smooth.
The script scrolling speed can be controlled by the announcer using the remote control, enabling single-person or dual-person operation.
Functions:
1.The system runs on Windows 11 24H2 64-bit operating system.
2.Text and background colors can be freely combined. Male and female anchors can separately select background and text colors to personalize their prompting scripts. Font and font size can be freely chosen. It supports custom display settings (font size, typeface, and color) for different roles.
3.Script entry and editing are easy, with simple operation and automatic formatting. Supports TXT and XML file formats.
4.Suitable for both live and recorded broadcasting in TV studios. The script is displayed with bright and clear characters. Paragraph formatting, bullet points, indentation, and line spacing are all configurable. Date and time can be inserted at any point in the script.
5.Dual-screen normal and mirror display is realized through software, making it more intuitive for both announcers and technical staff to operate.
6.Supports domestic minority languages such as Chinese, Tibetan, Mongolian, Dai, Uyghur, Korean, and international languages including English, Japanese, Korean, German, Russian, French, and Arabic.
7.The system automatically records the script. In the event of a power outage, the system will automatically locate and reopen the script upon power restoration, ensuring script integrity.
8.Relative scroll time and current time can be displayed on the same screen, with freely customizable size and color. Key sentences can be highlighted in color.
9.Multiple control terminals and prompting terminals can be synchronized over a network. The prompting director can group one or more terminals via software, enabling different hosts to read different scripts displayed on their respective prompting terminals. Within each group, control and prompting terminals can be flexibly designated as master or backup.
10.Supports 16:9 and 4:3 display settings. Prompter scripts can be edited online in real time, with live updates displayed instantly.
11.Fully supports font formatting customization, characters per line, font weight, line spacing, font color, background color, title color, and title background color.
12.All control terminals (including hand control, foot control, and remote control) and display terminals are equipped with status indicator lights.
13.Supports multiple display modes and text layout styles. All prompter controllers (hand, foot, and remote) allow individual adjustment of maximum speed, minimum speed, and speed increments.
In addition to forward, backward, page up, page down, and go-to-top buttons, the hand control unit also supports two custom buttons.
System Highlights
1.All metal parts are CNC-machined for high precision, high strength, and durability.
2.The triple-balance structure allows the camera and prompter to remain balanced front-to-back with minimal or no additional counterweight, reducing the burden on the tripod head and benefiting framing and camera movement.
3.The external hood is made of lightweight carbon fiber and features an innovative elastic retractable rubber ring for sealed lens connection, providing dust protection and ease of use.
4.Multiple prompting terminals can be synchronized over the network. A single remote control can control multiple prompting terminals simultaneously.
5.Can be integrated into studio automation systems. Via MOS gateway, it connects to the newsroom system to automatically update the prompter content in sync with the script system.
6.Accepts control commands from the studio automation system and runs automatically.
7.The prompting screen adopts passive fiber HDMI signal input to ensure safe and reliable prompter signal.
8.Supports network-based prompter functions. It can connect to a prompter server to automatically obtain content and receive centralized control commands.
9.Supports connection to hand control, foot control, and wireless hand control devices. Control signals can be uploaded and distributed via a network server.
Standard Configuration
1.2151A Prompter Structure Kit ×2
2.Embedded Prompting Host with Operating System / 21.5-inch Prompting Screen ×1
3.Studio Automation Prompting Control Software V2.0 ×1
4.Wireless Remote Control Pen ×1
